Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs

  • Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs
  • Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs
  • Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs
  • Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs
  • Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs
  • Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs
  • Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs
Place of Origin China
Brand Name FLAD
Model Number F-9800A
Minimum Order Quantity 2 rolls
Price Negotiation
Packaging Details high quality carton box packing or Hard tube.
Delivery Time 8-10 days
Payment Terms L/C, D/P, T/T, Western Union,Cash
Supply Ability 3320 rolls/day

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs Adhesive Permanent Pressure Sensitive Adhesive
Color White,Yellow,Red,Blue,Green,Brown,Fluo Yellow Processing Silk-Screen Printing, UV Printing
Size 1.22x45.7m Material Acrylic (PMMA)
Durability 7 Years Liner 100mic PET
Prismatic Film 350mic Special Feature Untearable, Screen Printable, Waterproof
Highlight

Reflective Sheeting Vinyl Sticker Roll

,

Prismatic Reflective Sheeting Vinyl Sticker Roll
Leave a Message
Product Description

Class 4 durability 7 years high intensity grade prismatic reflective sheeting vinyl sticker roll (HIP) for traffic signs



The principle of microprism reflection is based on the light in three-dimensional space, incident from a certain angle,three reflections occur in three perpendicular planes,and then reflect it back in the original direction of incidence. When the incoming light enters the microprism, after three secondary reflections, finally, the lights is reflected back to the source. This process is called prism reflection.



High intensity Grade Micro-Prismatic reflective sheeting is based on acrylic reflective film, good flexibility and excellent for computer cutting, very easy operated, the acrylic film is tearable. Very competitive prices for the area meanwhile have long time service life.



Product Description



Product item

Class 4 durability 7 years high intensity grade prismatic reflective sheeting vinyl sticker roll (HIP) for traffic signs
Size 1.22m*45.7m and customize
Net Weight 34kgs/ctn(1roll in one carton/hard tube)
Gross Weight 36kgs/ctn
surface film Acrylic
Properties Reflective Light
Adhesive Permanent pressure sensitive adhesive
Color White,Red,Blue,Green,Yellow,orange ,brown,Fluorescent yellow
Liner 100mic PE filim
Feature Untearable, Screen Printable, Waterproof
Durability 7 years
Printing Silk Screen printing, UV printing,Letter Signs
Bulk lead time 7-10 days more or less, based on your quantities
Delivery FOB Shanghai, CNF, CIF,
Terms of payment T/T
Product Type Micro Prismatic
Working Temperature 18-28ºC
Application Traffic Signs, traffic warning sign, conspicuity tape

Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs 0
Advantage

1. Micro-prism structure: advanced reflective technology with high retroreflection

2. Omni-directional: Uniform daytime and nighttime visual appearance

3. Easy constrution: Lettering in any direction, printable

4. Pressure sensitive adhesive: high quality adhesive

5. Wide angularity: Adapt to the visual needs of different cars and lanes

6. The product conforms to Chinese standard GB/T 18833-2012 Class 4

Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs 1

Feature:
1. Micro prism structure,PMMA material,superior brightness and angularity, excellent reflection

2.High temperature resisitance

3.Tear Growth Resistance, Scratch resistance, water/oil Resistance

4.Weather resistance, keep good reflection in the bad weather, like the raining day, foggy or dark condition

5.Permanent pressure sensitive adhesive, paste properties, fast strong bonding, easy to apply to any metal substrate surface

6.Dustproof, moisture proof, easy to erase.

7.Can be used for silk screen printing,digital printing, easy for computer cutting,Lettering film processing

8.Specialized PSA technology to ensure excellent adhesion ability

9. Good water resistance,corrosion resistance,solvent resistance

Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs 2

Storage:

It should be stored in a cool and dry area, preferably at 18~28ºCand 30~50% relative humidity and should be applied within one year of purchas

. Coefficient of retro-reflection

Observation angle Entrance angle coefficient of retro-reflection
White Yellow Red Green Blue Orange Brown
0.2° -4° 636 437 105 85 56 261 77
30° 259 206 43 33 21 112 30
0.5° -4° 460 367 91 71 37 203 57
30° 85 72 16 13 6.3 38 9.9

Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs 3
Notes:

The reflective sheeting is better to keep and cut between the 18-28ºC; when working, the working area and tools should be clean. The unused after opening, should be rolled back tightly along the primary direction and fixed, the inner tube diameter should be more than 10cm

Packing:

1. Standard packing: 1 roll/carton
2.As per customer requirement
3.Export packing-thick core and cartons, two sides with plug, put on pallets, wrap with shrink film

Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs 4

Application:


Used for permanent traffic signs and highway signs
a). Highway and city road traffic signs,retro- reflective marking for cars,
trucks, ships and other vehides
b). Personal safety supplies: bicycles, motocyles, etc
c).Vehicle: safety signs and decals
d).Industry safety signs
e). Parking signs: all construction signs
f). Temporary signs and night of physical activity
g). Conspicuity tape

Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs 5

Class 4 Durability 7 Years High Intensity Grade Prismatic Reflective Sheeting Vinyl Sticker Roll (HIP) For Traffic Signs 6

Delivery time:



7-15 days after receive the payment.
